| Model No. |
PLC-335P-IR2/PR |
| Imaging Device |
1/2.7″ Progressive CMOS |
| Scanning System |
Progressive Scanning |
| Min. Illumination |
0.05lux@F1.2 (AGC ON),0Lux with IR ON |
| Video Output |
BNC |
| Resolution |
5MP 2592（H）×1944（V） |
| Max, Framerate |
5AHD/5TVI: 5MP@20fps 4AHD/4CVI/4TVI: P@25fps N@30fps CVBS: 960H |
| Max. Aperture Ratio |
F1.6/F2.2 |
| Lens Type |
Fixed lens /2.8mm/3.6mm |
| Audio |
Audio over coaxial |
| Audio Range |
7m |
| IR Distance |
20m |
| On Screen Display |
English |
| Day & Night |
Ext / Color / B/W |
| Backlight Compensation |
Off / User BLC |
| Digital Noise Reduction |
2D DNR |
| Gain Control |
Auto |
| White Balance |
ATW |
| Electronic Shutter Speed |
Auto |
| Reverse |
Mirror |
| Video Transmission Distance |
MAX 300M （ Cable : 5C 2V） |
| Operating Temperature / Humidity |
-30°C ~ 55°C / 90% |
| Ingress Protection |
IP66 |
| Input Voltage/Current |
12V DC |
| Power Consumption |
IR OFF ≤ 0.8W, IR ON ≤ 4W |
| Colour / Material |
Plastic |
