PLC-335P-IR2
PLC-335P-IR2
PLC-335P-IR2
Plastic Dome 5 MP
• 1/2.5” Full HD CMOS Sensor
• 20 m IR
• Output: AHD/CVI/TVI
• 2.8 mm Lens
• IP65
Description
| Image Sensor | 1/2.5” 5 MP HD Color Image Sensor CMOS |
|---|---|
| Signal System | PAL/NTSC |
| Horizontal Resolution | 5 MP (2560 x 1920) |
| Lens | 2.8mm |
| IR LED | IR Range of 20 m with 12 SMD LED |
| Min. Illumination | 0.01 Lux (IR LED ON), 0.1 Lux (IR LED OFF) |
| Electronic Shutter | 1/50 s (1/60 s)-1/100,000 s (Auto/Fixed) |
| Video Output | AHD/TVI, 5 MP, 20fps/12.5fps, AHD/TVI/CVI, 4 MP, 30 fps/25fps |
| Exposure | Auto |
| Auto-gain | Yes |
| White Balance | Auto |
| BLC | Auto |
| Gamma Correction | 0.45 |
| S/N Ratio | ≥50 dB |
| DNR | 2 DNR |
| Video Output | 1.0 VP – P Composite Output (75Ω / BNC) |
| Frame Rate | 30 fps (60 Hz, 25 fps (50 Hz)) |
| D&N | Support ICR |
| Power Consumption | 1.2 W (4 W After IR LED is Powered on) |
| Housing | Plastic , IP65 |
| Power Source | DC 12 V (+/-15%) |
| Working Temperature | -20℃ – 50℃, 10% – 90% (Humidity) |
| Weight | 0.24 Kg |
| PLC-335P-IR2 | Data Sheet of PLC-335P-IR2 |
|---|
