| Model No. |
PLC-332P-IR2/PM |
| Image Sensor |
1/3.2″ CMOS |
| Resolution |
2MP |
| Image Size |
1920 x 1080 |
| Video Output |
AHD / TVI /CVI/CVBS |
| Image System |
PAL / NTSC |
| Electronic Shutter |
Auto; 1 / 50s ~ 1 / 100000s (PAL); 1 / 60s ~ 1 / 100000s (NTSC) |
| IR Distance |
10 ~20m |
| Frame Rate |
30fps(60Hz); 25fps (50Hz) |
| Min. Illumination |
0 lux (IR ON) |
| Lens |
2.8 mm |
| Lens Mount |
M12 |
| S / N Ratio |
≥52dB (AGC OFF) |
| Function |
Control OSD (COC Control) |
| Day & Night |
ICR |
| Digital WDR |
Yes |
| Digital NR |
Yes, 2D DNR |
| AGC |
Yes |
| Auto White Balance |
Yes |
| BLC |
Yes |
| FLC |
Yes |
| Defog |
No |
| HLC |
No |
| Sharpness |
Yes |
| Mirror |
Yes |
| Smart IR |
Yes |
| Image Setting |
Yes |
| Defect Correction |
Auto |
| Language |
Chinese and English |
| Angle Adjustment |
Pan: 0°~360°; Tilt: 0°~90°; Rotation: 0°~360° |
| Power Supply |
DC12V (± 10%) |
| Power Consumption |
IR OFF: < 1W; IR ON: < 3W |
| Working Environment |
– 30 °C ~ 50 °C, 10 % ~ 90 %（relative humidity） |
| Dimensions (mm) |
Ф 77.5 x 67.6 |
| Weight (net) |
Approx. 0.17KG |
