| Model No. |
PLC-328M-IR5/PM |
| Image Sensor |
1/2.5″ CMOS |
| Resolution |
8MP |
| Image Size |
3840×2160 |
| Video Output |
AHD / TVI /CVI /CVBS |
| Image System |
PAL / NTSC |
| Electronic Shutter |
Auto |
| LED Distance |
30 ~ 50 m |
| Frame Rate |
15fps |
| Min. Illumination |
Color: 0.01 lux@F1.2, AGC ON; B/W : 0 lux with IR |
| Lens |
2.8 mm |
| Lens Mount |
M12 or D14 optional |
| S / N Ratio |
≥52dB (AGC OFF) |
| Ingress Protection |
IP 67 |
| Function Control |
OSD (COC Control) |
| Day & Night |
ICR |
| Digital WDR |
No |
| Digital NR |
Yes |
| AGC |
No |
| Auto White Balance |
Yes |
| BLC |
Yes |
| Defog |
No |
| LSC |
No |
| Saturation |
Yes |
| Sharpness |
Yes |
| Contrast |
Yes |
| Smart IR |
Yes |
| Image Setting |
Yes |
| Defect Correction |
Auto |
| Language |
11 languages |
| Angle Adjustment |
Pan: 0°~360°; Tilt: 0°~90°; Rotation: 0°~360° |
| Power Supply |
DC12V (± 10%) |
| Power Consumption |
IR OFF: < 2W; IR ON: < 5.5W |
| Working Environment |
– 30 °C ~ 50 °C, 10 % ~ 90 % |
| Dimensions (mm) |
217.7 x 80.5 x 80.5 |
| Weight (net) |
Approx. 0.57KG |
