| Model Number |
PLC-328M-IR3/PR |
| Imaging Device |
1/2.7″ Progressive CMOS |
| Total Pixels |
3872（H）×2180（V) |
| Effective Pixels |
3840（H）×2160（V） |
| Scanning System |
Progressive |
| Min. Illumination |
0.05lux@F1.2 (AGC ON),0Lux with IR ON |
| Video Output |
BNC |
| Resolution |
8MP 3840（H）×2160（V） |
| Max, Framerate |
AHD/TVI/CVI: 8MP@15fps CVBS: 960H |
| Focal Length (Zoom Ratio) |
3.6MM |
| Max. Aperture Ratio |
F2.0 |
| Angular Field of View |
H:90.84° / V:48.8° / D:108.73° |
| Min. Object Distance |
0.2m |
| Lens Type |
Fixed lens |
| Viewable length |
20M |
| On Screen Display |
English |
| Day & Night |
Smart / Auto / Colour / B/W |
| IR Range |
30 meters |
| Backlight Compensation |
GLOBAL / BLC |
| Wide Dynamic Range |
D-WDR (Off/On) |
| Digital Noise Reduction |
2D DNR |
| Gain Control |
HIGH |
| White Balance |
ATW |
| Electronic Shutter Speed |
AUTO |
| Reverse |
Mirror |
| Remote control interface |
ACP (AHD Coax Protocol) |
| Video Transmission Distance |
MAX 300M （ Cable: 5C 2V） |
| Operating Temperature / Humidity |
-30°C ~ 55°C / 90% |
| Ingress Protection |
IP66 |
| Input Voltage/Current |
12V DC |
| Power Consumption |
IR ON : 5W, IR OFF : 1.5W |
| Color / Material |
Metal |
| Safety |
CE LVD |
| EMC |
CE EMC、FCC |
| ROHS |
RoHS2.0 |
