| Model No. |
PLC-1504H1/PR |
| Inputs |
4Mbps ~20Mbps, IP Bandwidth deful is 4Mbps |
| Bandwidth out |
32Mbps |
| Analog video-input |
4CH inputs |
| IP Video Input |
1ch, (only IP up to 5ch) |
| Composite Video Input |
up to 5 ch (Analog video + IP video) |
| Compression |
Audio: G.711a; Video: H.264/H.265 |
| Display resolution |
Analog: 5MP-Lite:20fps ,4MP-Lite:30 fps,1080P/720P/960H:30fps IP:1080P/720P |
| Speed |
Analog:5MP-Lite:20fps (each ch), 4MP-Lite:30fps (each ch), 1080P/720P:PAL:25fps (each ch)/NTSC:30fps (each ch) IP: PAL:25fps (each ch)/NTSC: 30fps (each ch) |
| Event |
MD (Sensitivity Level 1~8) Video loss Beep, Email, Push notification to Mobile APP |
| Playback function |
Fast forward / backward (2x, 4x, 8x,16x) Slow forward (1/2x, 1/4x, 1/8x,1/16x) |
| Playback |
5MPlite:80fps ,4MPlite: 120fps ,1080P: 120fps,720P:120fps |
| VGA |
N/A |
| HDMI |
1（1024*768, 1280*720, 1280*1024, 1440*900, 1920*1080 ,EDID） |
| Ethernet |
1 RJ45 10/100Base-T |
| USB |
USB2.0*2(front) |
| Audio |
N/A |
| HDD |
1 SATA HDD, up to 8TB |
| Dimension (WxDxH) |
230*215*47mm |
| Input Voltage/Current |
DC12V/2A |
| Power consumption (excluding hard disk) |
3.6W |
| Operating Temperature/Humidity |
Temperature: 0°C~+40°C (32°F ~ 104°F) ,Humidity : Less than 90%RH |
